Novec 1230 Calculation Sheets: Sizing of novec 1230 system is technique which is used to by engineers to make fire stop system. they obtains novec 1230 info using multiple techniques one of the most common technique is calculation sheets , Excel format and piping design. they Use their system info to make fire stop on the places like rooms, buildings etc. this is completely essential all over the world and still its very popular. they gets room volume, agent mass, cylinder count and all that stuff to make system work properly.

Why Precise Sizing Matters

• Effective Protection: Delivers the exact agent concentration needed to extinguish fires quickly in data centres, museums, and telecom facilities.
• Code Compliance: Meets NFPA 2001 hold-time and discharge requirements, safeguarding your design against review comments.
• System Efficiency: Avoids over-sizing (wasted material and cost) or under-sizing (inadequate suppression) by automating complex formulas.

Novec 1230 Calculation Sheets: Key Features of the Excel Calculation Sheets

1. Room Volume & Agent Concentration

   • Input room length, width, and height to calculate protected volume.
   • Select hazard class (Class A, B, C, or sensitive electronic) to set the required concentration (% by volume).

2. Agent Mass Determination

   • Applies the formula:Mass (kg)=V×(C100)×ρ \text{Mass (kg)} = V \times \left(\frac{C}{100}\right) \times \rhowhere V = volume, C = design concentration, ρ = Novec 1230 density (default values provided).

3. Cylinder & Storage Sizing

   • Estimates how many standard-capacity cylinders (e.g., 14 kg, 28 kg) you’ll need per protected zone.
   • Includes temperature and pressure correction factors for accurate storage calculations.

4. Piping & Discharge Time Check

   • Calculates hydraulic loss through piping layouts, ensuring the system discharges within the NFPA 2001-mandated 10 seconds.
   • Provides K-factor lookup tables for common fittings and orifice sizes.

5. Hold-Time Verification

   • Confirms that agent concentration remains above the minimum required level for the code-specified hold time (typically 10 seconds).

READ ALSO: Data Center Cooling Systems: Everything You Need to Know

Novec 1230 Calculation Sheets: How to Use

1. Download & Open: Enable editing in Microsoft Excel.
2. Enter Room Data: Fill in your protected space’s dimensions and select the hazard classification.
3. Review Calculated Mass: Navigate to the “Agent Mass” tab to see required kilograms of Novec 1230.
4. Determine Cylinder Count: Check the “Storage” tab for recommended cylinder quantities and layouts.
5. Design Piping Layout: Use the “Hydraulics” tab to input pipe lengths and fittings; verify discharge speed.
6. Export Your Report: The “Summary” sheet compiles all results into a formatted report for submittal.
