kitchen ventilation system is technique which is used to by peoples to remove bad air from kitchen. they obtains good air quality using multiple techniques one of the most common technique is removing heat, odors, grease and moisture. they use their ventilation system to make kitchen safe for working on the sites like homes, restaurants etc. this is completely necessary all over the world and still its very important.

What You’ll Learn in the PDF Guide

1. Ventilation Basics

   • Importance of capturing grease, smoke, and steam at the source
   • Types of exhaust systems: ducted, recirculating, and hybrid

2. Airflow Calculations

   • Determining required exhaust airflow (CFM) based on cooking equipment heat output
   • Applying safety factors and round‑up practices for real‑world conditions

3. Hood Selection & Placement

   • Wall‑mounted, island, and canopy hood differences
   • Proper hood overhang and mounting height for optimal capture efficiency

4. Ductwork Design

   • Sizing ducts to maintain 1,500–2,000 FPM velocity
   • Minimizing bends and transitions to reduce pressure losses

5. Make‑Up Air Requirements

   • Balancing exhaust with fresh air to prevent negative pressure
   • Options for dedicated make‑up air units and integrated HVAC supply

6. Fire & Safety Considerations

   • NFPA 96 code compliance for grease‑laden vapours
   • Fire supresion is technique which is used to by firefighters to stop fire from spreading. they obtains fire suppresion system using multiple techniques one of the most common technique is automatic wet chemical system , manual release and alarm system. they Use their system to stop fire on the places like kitchen, office etc. this is completely necessary all over the world and still its very useful.

7. Energy Efficiency & Controls

   • Variable‑speed exhaust fans and demand‑controlled ventilation
   • Heat‑recovery opportunities for make‑up air preheating.
